H Beam Plasma Profile Cutting Robot Machine
H Beam Plasma Profile Cutting Robot Machine
![H Beam Plasma Profile Cutting Robot Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7817789.jpg?x-oss-process=image/resize,m_pad,l_600/quality,Q_90)
![H Beam Plasma Profile Cutting Robot Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7817789.jpg?x-oss-process=image/resize,m_pad,l_100/quality,Q_90)
![H Beam Plasma Profile Cutting Robot Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7817788.jpg?x-oss-process=image/resize,m_pad,l_100/quality,Q_90)
Categories | H Beam Cutting Machine |
---|---|
Brand | YOMI CNC Cutting&Welding Machinery |
Model | YM-600,YM-1000, YM-1250, YM-1500 |
Cutting method | Plasma/Flame |
Plasma power source | Herpertherm XPR300A |
Plasma cutting thickness | Pierce cutting thickness 1-45mm |
Oxy fuel cutting thickness | Vertical cutting thickness 6-32mm |
Effective cutting length | 12m |
Cutting precision in length | ±1.5mm |
Beam Web Height(YM-600) | 100-600mm |
YM-1000 | 100-1000mm |
YM-1200 | 200-1250mm |
YM-1200 | 200-1250mm |
Beam flange width | 100-600mm |
Update Time | Jul 27,2024 |
Detail Information
Description
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7807632.jpg?x-oss-process=image/quality,Q_90)
CNC Beam Plasma Cutting Machine
Application:Profile Plasma Cutting Machine is consisted of cutting unit, roller frame,feeding trolley and rail, finished profile conveying station. It is a hot cutting processing equipment for H beam, I beam, Channel steel, Angle steel,and their inter-sectioning shape.
Applicable materials:Carbon structural steel, stainless steel
Technical Parameters
H beam/I beam/Channel steel/angle steel
|
YM-XH-600 | 100-600mm |
|
YM-XH-1000 | 100-1000mm | ||
YM-XH-1200 | 200-1250mm | ||
YM-XH-1500 | 600-1500mm | ||
Cutting method | Plasma/Flame | ||
Plasma power source | Herpertherm XPR300A | ||
Plasma cutting thickness | Pierce cutting thickness 1-45mm | ||
Oxy fuel cutting thickness | Vertical cutting thickness 6-32mm | ||
Cutting speed
|
10~2000mm/min
|
||
Moving speed
|
10~6000 mm/min
|
||
Maximum profile weight to be cut |
5000Kg Note:Can customized according to offered max weight
|
||
Beveling cutting | ±45 degree | ||
Profile cutting form | Fixed length straight cut, fixed length oblique cut and end socket function | ||
Cutting accuracy execution standard | ISO9013-2002\ISO8206-1991\ JB/T10045.4-1999JB |
Cutting Efficiency Measurement
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7807967.jpg?x-oss-process=image/quality,Q_90)
Profile specifications:
340*250 as below drawing.( Max cutting length 3500mm. The main cutting process includes single and double-sided beveling, over-welded hole and web shaped track)
Adopt hypertherm XPR300 fine plasma power source 170A current, Process No. 1152 Air + Oxygen
Provides stable source pressure and flow (air + oxygen) on site
Cutting result record:
1.Single structural profile cutting time is 8 minutes.
2.The distance between the two over-welded holes is 6-8 mm.
FEATURES
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808130.jpg?x-oss-process=image/quality,Q_90)
Cutting Station
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808143.jpg?x-oss-process=image/quality,Q_90)
Profile Feeding Unit and Traverse Frame
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808144.jpg?x-oss-process=image/quality,Q_90)
Clamp Feeding Unit
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808145.jpg?x-oss-process=image/quality,Q_90)
Finished Profile Feeding Out and Storage Area
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808146.jpg?x-oss-process=image/quality,Q_90)
Laser test function introduction
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808152.jpg?x-oss-process=image/quality,Q_90)
Human Machine Interface,Clear touch screen
VEDIO
Application
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808157.jpg?x-oss-process=image/quality,Q_90)
Customers’ Project
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7807399.jpg?x-oss-process=image/quality,Q_90)
Customers’ Project
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808158.jpg?x-oss-process=image/quality,Q_90)
![H Beam Plasma Cutting Machine](https://icdn.tradew.com/file/202211/1575595/jpg/7808159.jpg?x-oss-process=image/quality,Q_90)
